YHD32 Four-column Hydraulic Press



Description of hydraulic press:
There are several different kind of hydraulic presses for different purpose, such as four-column universal hydraulic press, single-action hydraulic stamping press, double action hydraulic stretching press, etc. If you don’t know how to choose, pleaselet us know your detailed requirements or product information and we can give you the best suggestion.



Description of hydraulic press:
There are several different kind of hydraulic presses for different purpose, such as four-column universal hydraulic press, single-action hydraulic stamping press, double action hydraulic stretching press, etc. If you don’t know how to choose, pleaselet us know your detailed requirements or product information and we can give you the best suggestion.

Application of YHD-32 four-column hydraulic press:
This series is suitable for stretching, bending, flanging, cold extruding, punching and cutting purpose. It can also be used for forming plastic & insulation materials.

Optional accessories of YHD-32 four-column hydraulic press:
Punching & cutting cushion device; movable worktable; phototube safety device; oil cooling device; touch screen; PLC control, etc.

Main technical data of YHD-32 four-column hydraulic press:

Item YHD-32
40 63 100 100 160 160B 200 315 400 500 500C
Nominal force KN 400 630 1000 1000 1600 1600 2000 3150 4000 5000 5000
Kick-out force KN 120 190 190 190 400 400 400 630 630 1000 1000
Hydraulic pressure MPa 25 25 25 25 25 25 25 25 25 25 25
Max. slide stroke mm 450 500 600 700 700 700 800 800 900 900 900
Max. kick-out stroke mm 150 200 200 200 200 200 250 300 300 350 350
Max. opening height mm 700 750 880 880 900 1000 1100 1250 1250 1500 1500
Stroke speed Quick-down mm/s 20 20 22 120 100 100 100 100 100 100 100
working mm/s 14 14 14 14 12 12 8 6-8 5-7 5 6
returning mm/s 45 120 47 120 70 70 52 60 45 70 70
Worktable size L-R mm 500 580 720 720 680 1000 1000 1260 1240 1400 2400
F-B 460 500 580 580 620 800 900 1200 1200 1400 1400
Motor power KW 5.5 7.5 7.5 7.5 7.5 7.5 15 15 15 37 37

Product display
