JY21G High Speed & High Precision Press



Main features of JY21G high speed & high precision press:
 --D-shaped half-seal structure, high strength, high rigidity
 -- Combined dry-type pneumatic friction clutch
 -- Air cell type balancing device
 -- Compulsive lubricating system
 -- World famous brand PLC
 -- World renowned brand electric components
 -- Hydraulic overload protection device
 -- Motorized adjusting die height, digital displaying
 -- Electro-cam device, stop at top dead point intelligently and also many other safety manners

Main technical data of JY21G high speed & high precision press:
 Item JY21G-63 JY21G-80 JY21G-125 JY21G-160 JY21G-200
Nominal force kN 630 800 1250 1600 2000
Nominal stroke mm 1.5 2
Slide stroke mm 30 40
SPM min-1 150-250 90-120
Max. die height mm 300 350 380 400 450
Die height adjustment mm 60
Distance between slide center to frame mm 300 320 350 380 390
Worktable size mm 580x900 620x1090 680x1220 740x1300 760x1350
Worktable thickness mm 140 160 180 180 200
Bore size on worktable mm 100x350 150x400 200x580 200x700 200x750
Slide size mm 400x480 500x800 620x980 650x950 680x1000
Shank hole mm Φ50×80 Φ50×80 Φ60×80 Φ65×90 Φ65×90
Clearance between columns mm 870 910 1200 930 970
Motor Power kW 11 15 18.5 22 30
Outline Size (FB×LR×H) mm 2050x1300
x2700
2500x1600
x2950
2620x1650
x3200
2330x1870
x3240
2560x1900
x3320
Net weight (about) kg 10000 11000 16500 18500 19880

Product display
