Automatic tank welding machine

Automatic tank welding machine is special for welding various kinds of tank body, both round tank and special shaped tank. This automatic tank welding machine adopts advanced PLC control, micro electronics and inverter technology to achieve one pass forming. We also have cross type auto tank welding machine only for round tanks.






Finsihed product by tank welding machine


Main technical data of automatic tank welding machine

Max. diameter

3500mm, can be customized

Min. diameter

1200mm

Gantry

Gauge

4000mm

Rail length

18000mm, can be customized

Rotating device

Gauge

1500mm

Rail length

16000mm (user supplied)

Welding speed

50-1000m/min

Gantry longitudinal returning speed

2800mm/min

Welding position

Flat position welding

Diameter of welding wire

1.0-1.6mm

Welding method

The Submerged Arc Welding

Gantry drive

AC Frequency Converter, Stepless speed regulation

Double sides drive

Rotating device drive

AC Frequency Converter, Stepless speed regulation

Cable Conveying type

Pulley type

Welding profile modeling

Automatic profile modeling

Weld width

5-12mm

Welding seam monitoring mode

manual

Power

AC 380V, 50Hz, can be customized

Main motor power

31KVA




Product display
