PU Injection Machine

Description of PU injection machine:
There are different configured PU injection machines for different purpose. We can provide different kind of PU injection machines according to your detailed requirements.

I Low pressure PU injection machine:

Item Data
Main pump motor power 5.5kW
Mixing head motor power 0.55kW
Hydraulic pump motor power 2.2kW
Automatic glue filling motor power 1.5kW x 2
Flux 5~30kg/min
Capacity of tanks for polyurethane glue 180kg x 2, auto filling glues
PLC automatic control PLC programmable, automatically heating, injecting, cleaning and blowing; PLC can save 99 programs
Piston type counting pump adjusting precision 0.05%
Generating pressure 8-10MPa
Air compressor needed 0.8m3 (prepared by Buyer)
Machine weight About 800kg
Machine dimension About 1370 x 1350 x 2250mm

II High pressure polyurethane foam injection machine:
Item Data
Main pump motor power 15kW x 2
Mixing motor power 0.55kW
Hydraulic pump motor power 2.2kW
Flux 40-400kg/min
Injecting time 0.1-99.9s
Injecting pipe high pressure protection Pressure gauge with electric contact
Filters for Polyol and ISO glues DN110 self-clean filter
Hydraulic station Tank volume 20L
High pressure mixing head High precision, hydraulic control, L-type, self-clean, solvent free;
Life more than 300,000 times;
Nozzle OD: 24mm
Heating power for two tanks 2kW x 2;
Temperature control for tank heating digital temperature controller
Auto-filling devices for two tanks Self-absorbing pumps, motor power 1.5kW
Capacity of tanks for polyurethane glue 180kg x 2
PLC automatic control PLC programmable, automatically heating, injecting, cleaning and blowing; PLC can save 99 programs
Piston type counting pump adjusting precision 0.05%
Generating pressure 80-100MPa
Suspending arm 2.5m long, 270°rotating, both horizontally and vertically injecting
Dimension of main body About 1590 x 1200 x 2400mm
Dimension of tanks 720 x 1550 x 2400mm
Weight About 2500kg

Product display
