Polyurea Spray Machine



Application of polyurea spray machine:
Polyurea spray machine is suitable for various construction, can spray a variety of two-component materials, such as polyurethane elastomer, polyurethane foaming materials, etc. It is widely used in embankment waterproof, pipeline corrosion, auxiliary cofferdam, tanks, pipe coating, cement layer protection, wastewater disposal, roofing, basement waterproofing, industrial maintenance, wear-resistant linings, cold storage insulation, wall insulation, etc.

Features of polyurea spray machine:
-- Take 160 cylinder supercharged for high-rise building construction
-- Small volume, light weight, low failure rate, simple operation, easy mobility.
-- Advanced ventilation method, guarantee working stability
-- Minimizing spraying congestion with 4-layers-feedstock device
-- Multi-leakage protection system to protect operator safety
-- Equipped with emergency switch
-- Digital counting system
-- 380V heating system enables rapid warming of raw materials to the best state
-- Spraying gun with small volume, light weight and low failure rate, etc.
-- Lifting pump adopts big change ratio method

Main technical data of polyurea spray machine:

Item Data
Model number GZ-5200 GZ-5600
Flux capacity 2-12kg/min 2-12kg/min
Working pressure 22MPa 24MPa
Heating power 18kW 20kW
Equipped pipe length 15 meters heating pipe (can be extended to 120m)
Air compressor 0.5-0.8MPa (to be provided by buyer)
Machine dimension 850 x 1000 x 1300mm
Machine weight 195kg
Proportion between A and B 1 : 1
Driven type Pneumatic
Electric power 380V, 3P, 50Hz

Product display
