Stator Winding Machine - Double Station



Description of double-station stator winding machine:
This stator winding machine is suitable for winding multi-layer, multi-section coils for stators. When one station is under winding, another station can release winding dies with finished coils and so this machine never stops.
Special winding controller can preset automatic stitch, initial point for winding, slow-speed start, slow-speed stop, both stations stop, automatic return back to origin, automatic start, etc.
This machine is suitable for winding coils used in those different kind of big-size 3-phase motors and generators, etc.

Main technical data of double-station stator winding machine:
Model SR160 SR250
Suitable wire   diameter Φ0.3~1.2mm Φ0.5~1.6mm
Winding die   diameter Φ100-350mm Φ200-550mm
Transferring   distance ≤250mm ≤250mm
No-load speed 1500rpm 800rpm
Power supply 220V, single phase, 50/60Hz
Motor power 1. 5kW 2.2kW
Machine weight About 900kg About 1200kg
Dimension (L x W x H) 2000x1450x1500mm 2000x1550x1650mm

Product display
