Bra Cup Edge Trimming Machine



I Description of bra cup edge trimming machine:
This machine is specially designed for trimming edge of foam or fabric bra cups.

II Main features of bra cup edge trimming machine:
1) Simple structure, less failure, good cutting performance, quick cutting speed
2) Compulsive lubricating system, lessen wear, lengthen service life
3) Adopts electronic delay circuit control bottom limit of cutting, high precision, good cutting result.
4) Distance between rocker arm and worktable can be adjusted by handle wheel, simple and reliable.
5) Adopts flywheel structure, instantaneous cutting, less power consumption.

III Main technical data of bra cup edge trimming machine:

Item MX-15 MX-20
Rated cutting force 15T 20T
Main driving motor power 1.5kW 1.5kW
Worktable size 770 x 420mm 900 x 500mm
Cutting stroke 60-250mm
Production speed 1000 times / min
Machine size 770x760 x1400mm 900x500 x1400mm
Machine weight 650kg 750kg

Product display
